Rhinoplasty for Middle Eastern Noses
Rod J. Rohrich, M.D., Ashkan Ghavami, M.D.

Background: Rhinoplasty remains one of the most challenging operations, as exemplified in the Middle Eastern patient. The ill-defined, droopy tip, wide and high dorsum, and thick skin envelope mandate meticulous attention to preoperativeevaluation and efficacious yet safe surgical maneuvers. The authors provide a systematic approach to evaluation and improvement of surgical outcomes in this patient population.

Methods: A retrospective, 3-year review identified patients of Middle Eastern heritage who underwent primary rhinoplasty and those who did not but had nasal photographs. Photographs and operative records (when applicable) were reviewed. Specific nasal characteristics, component-directed surgical techniques, and aesthetic outcomes were delineated.

Results: The Middle Eastern nose has a combination of specific nasal traits, with some variability, including thick/sebaceous skin (excess fibrofatty tissue), high/wide dorsum with cartilaginous and bony humps, ill-defined nasal tip, weak/thin lateral crura relative to the skin envelope, nostril-tip imbalance, acute nasolabial and columellar-labial angles, and a droopy/hyperdynamic nasal tip. An aggressive yet nondestructive surgical approach to address the nasal imbalance often requires soft-tissue debulking, significant cartilaginous framework modification (with augmentation/strengthening), tip refinement/rotation/projection, low osteotomies, and depressor septi nasi muscle treatment. The most common postoperative defects were related to soft-tissue scarring, thickened skin envelope, dorsum irregularities, and prolonged edema in the supratip/tip region.

Conclusions: It is critical to improve the strength of the cartilaginous framework with respect to the thick, noncontractile skin/soft-tissue envelope, particularly when moderate to large dorsal reduction is required. A multitude of surgical maneuvers are often necessary to address all the salient characteristics of the Middle Eastern nose and to produce the desired aesthetic result. (Plast. Reconstr. Surg. 123: 1343, 2009.)

Rhinoplasty remains as one of the most challenging and humbling aesthetic operations. The Middle Eastern nose perhaps best exemplifies the inherent difficulties that the rhinoplasty surgeon faces in providing predictable, long-lasting improvement in nasal appearance while battling postoperative healing forces. Middle Easterners have traditionally played an important role in the rhinoplasty patient base worldwide, with numbers continuing to increase. Understanding the physical and social characteristics of this ethnic group is important for any surgeon who performs rhinoplasty and requires a careful evaluation.

It is critical to avoid the creation of “racial incongruity” in non-Caucasian noses, which produces an imbalance in ethnic facial features and signifies an “operated-appearing nose.”1 A Caucasian- appearing nose on a Middle Eastern patient with Fitzpatrick IV skin type and other non-Caucasian facial traits presents as “overoperated” and awkward. Although an “accepted standard of beauty” may exist,1–4 Middle Eastern patients frequently want to retain specific ethnic traits, such as a higher dorsum and less obtuse nasolabial and columellar- labial angles relative to their Caucasian counterparts. This concept is similar to performing rhinoplasty in the male patient, in which masculine features should be preserved.

Young women constitute a large proportion of the patient base, making it important to include the patient’s parents in the details of the preoperative analysis, operative plan, and informed consent procedure. This produces a more “family-friendly consultation.” Furthermore, Middle Eastern patients tend to be “perfectionists,” and desire active participation in formulating the operative plan. Although this can be very helpful and illuminating to the surgeon, he rationale for the operative plan and the potential short- and long-term complications should be thoroughly discussed and documented. Preoperative imaging software can be invaluable in this discussion. In addition, privacy is cherished in most Middle Eastern cultures, and this became a formidable obstacle in obtaining photographic consent for our study.

As with any aesthetic procedure, the surgeon should only perform an operation that falls within his or her aesthetic judgment and ethical boundaries. Even if insisted on by the patient, creating a marked nasofacial/ethnic imbalance may not be in the best interest of the patient or the surgeon.

The Middle Eastern nose possesses important morphologic features that exist on a spectrum between the African-American nose1,10–14 and the Caucasian nose. Although similar nasal features are shared with African American, Mediterranean, and Hispanic/Mestizo13–16 ethnic subgroups, significant distinctions must be recognized for an individualized, “ethno-sensitive” surgical approach.

“Middle Eastern” commonly refers to people of Arabic, Turkish, North African, or Persian descent. Although specific ethnic delineations and geographical distinctions can be made, they are beyond the scope of this report. Furthermore, many of the cultural traits in the region have become intertwined over centuries. For example, the Parsi people have both Indian and Persian roots. In a review of Middle Eastern rhinoplasty techniques, Bizrah6 divides the Middle Eastern population into the Middle East, North African, and Gulf regions

The Middle Eastern nose seen on anteroposterior and lateral views is characteristic and distinct from other ethnic groups (Fig. 1). For our purpose, the term Middle Eastern refers to patients from North African countries (i.e., Morocco, Algeria, Libya, and Egypt), Gulf countries (i.e., Saudi Arabia, Iraq, United Arab Emirates, Kuwait, Iran, and Oman), and other ethnic regions (i.e., Turkey, Lebanon, Syria, Armenia, Afghanistan, Pakistan, and India).6

Overgeneralization regarding the nasal characteristics of specific ethnicities should be avoided. Ofodile and James17 describe the vast anatomical variations of the African American nose. However, an individualized, systematic approach to rhinoplasty in African Americans can help guide the operative plan, as described by Rohrich and Muzaffar.1 Like other ethnic subtypes the Middle Eastern nose exhibits a varied combination of specific anatomical characteristics. The goals of this study are to (1) define the more common nasal characteristics of the Middle Eastern nose; (2) describe a systematic open rhinoplasty approach that successfully addresses each nasal component; (3) define strategies that reduce the unpredictability of postoperative healing forces; and (4) emphasize the prevention of racial incongruity.

A retrospective rhinoplasty database search of 3 consecutive years was conducted to select out patients of Middle Eastern origin (n
36). Middle Eastern patients were selected out based on name recognition by the junior author (A.G.) and by history. A chart review of these patients was conducted and included detailed analysis of standardized preoperative and postoperative photographs and a review of the operative note. We also evaluated available nasal photographs of Middle Eastern patients who had not desired or undergone rhinoplasty , yielding a total number of noses analyzed.

In addition to standard nasofacial analysis, an ethnically focused nasal analysis was performed that centered on the specific nasal features of the Middle Eastern nose. This included a systematic evaluation of the Fitzpatrick skin type, skin thickness/ sebaceous quality, dorsum/radix position and contour, adequacy of nasal length, orientation and strength of the lateral crura, presence of nasal deviation, nostril-tip imbalance, degree of alar flaring (alar base position), columellar/medial crura length and integrity, and presence/absence of a hyperdynamic tip (animated view). The frequency of these preoperative characteristics is listed. Morphologic traits that were present less than 20 percent of the time are stratified as “infrequent.”

Based on detailed evaluation of 71 Middle Eastern American patients, a varied combination of the nasal characteristics were present. The most common features are shown in Figure 1, and a more detailed list is provided in Table 1, with percentage frequencies. Although some North African and Arabian ethnic groups demonstrate nasal features that are similar to African American, Asian,19 and Hispanic noses the Middle Eastern nose lacks certain features that often predominate in other ethnic subgroups (Table 2). Figure 2 depicts an ethnically focused nasal analysis that includes a systematic evaluation of the Fitzpatrick skin type; skin thickness/ sebaceousness; dorsum/radix position; nasal length; orientation and strength of the lower lateral, middle, and medial crura; nostril-tip imbalance; alar flaring; alar base position; and presence of a hyperdynamic tip.

Creation of nasal balance based on normative measurements is aesthetically pleasing (Fig. 2). However, the avoidance of “ethnic asymmetry” is crucial and can be prevented by not overcorrecting beyond preoperatively planned guidelines.
The nasolabial angle (and columellar-labial angle) should not exceed 95 degrees, and tending toward undercorrection is best. Standard nasal ratios may be used as a guide for treatment and evaluation, incorporating deviation from Caucasian norms (i.e., sharp supratip break). Patients may request specific changes be made, such as a very defined or narrowed tip; however, both the surgeon and patient must arrive at a balanced, well-informed decision. Use of preoperative patient image software is a powerful education tool and aids in this process. Downplaying the postoperative results image may also prevent unrealistic expectations. The goals of rhinoplasty in the Middle Eastern patient are listed in Table 3, and outcomes are demonstrated through case examples that depict the morphologic variations.

Skin and Soft-Tissue Envelope

One of the greatest challenges in Middle Eastern rhinoplasty is management of the poorly contractile, thick, sebaceous skin envelope. Patients frequently have Fitzpatrick skin types III through V, with Middle Eastern patients of more northern regions (Northern Iran, Armenia, and Turkey) demonstrating lesser Fitzpatrick scores. Skin characteristics consist of thick nasal skin throughout, which is most challenging at the supratip and infratip lobule. Skin texture often displays a high degree of sebaceousness, particularly the dorsum and nasal tip. Oral tretinoin (Accutane; Roche US Pharmaceuticals, Nutley, N.J.) or topical retinoic acids can be prescribed in severe cases to reduce the density of sebaceous skin.

Intraoperative evaluation demonstrates moderate to large amounts of fibrofatty tissue (up to 4 mm thick) in the supratip, interdomal space, and between the medial crura. Wide soft-tissue undermining is often required to reduce the fibrofatty infiltration. The abundant presence of intercartilaginous fibrofatty tissue may be partly responsible for the decreased stability and strength of the cartilaginous frame (Fig. 3). The fibroligamentous nasal attachments20 appear weakened by the abundant fatty deposits.

On external palpation, weakness of the tip cartilages and compressibility in the region of the domes can give a sponge-like feel to the nasal tip and lobule. The strength of the nasal base platform and middle/medial crura is assessed by placing direct pressure on the domes and pressing posteriorly toward the nasal spine. Lack of resistance from the tip/lobule complex may be observed as it collapses away from the high septal angle. This indicates a weak nasal base platform, supportive cartilages (i.e., short/thin middle crura and medial crura), and ligamentous attachments. The intrinsically fragile tip complex is usually located posterocaudal to the high anterior septal angle, which creates a biomechanical disadvantage for the unsupported/weak middle and medial crura. Vertically oriented lower lateral crura further add to this phenomenon and increase the risk of postoperative loss of tip position and external valve function, as elegantly described by Constantian

Careful resection of intercartilaginous fatty tissue1, allows for greater stability when replaced with stronger and longer strut grafts. As with the African American nose, extensive defatting and scoring in the supratip may be indicated to promote greater soft-tissue contracture. This should not violate the subdermal plexus, which can produce irregularities and vascular embarrassment.

The nasal dorsum is frequently wide and high in the Middle Eastern patient. The dorsal hump has contributions from the paired nasal bones (usually long), the ascending process of the maxilla, the cartilaginous septum, and the upper lateral cartilages. The contribution of each of these structures will dictate the degree to which each must be altered and a component (incremental) dorsal hump reduction becomes particularly useful.30 This graduated technique is critical, as excessive dorsum reduction can produce significant racial incongruity through greater loss of dorsal height and a “scooped out” dorsum. The radix can be high and overprojecting (men and women), and burring or rasping of the radix may be required in very select cases.31 It is critical that the balance between dorsal height and radix projection be maintained. Overresection of one and/or the other will result in an imbalanced, overoperated nose. Occasionally, crushed radix grafts may be necessary at the radix but are not very predictable.

Osteotomies, if performed, are made using a low-to-low percutaneous technique, because bony width usually starts at the ascending process of the maxilla.The “low osteotomy” position circumvents asymmetric/unbalanced dorsal aesthetic lines and lateral bony stepoffs. Reduction of a significant dorsal hump can increase bony and midvault width by means of an open roof, and a combination of osteotomies and spreader grafts is commonly indicated. In addition, with the presence of long nasal bones, osteotomies can further narrow an already attenuated airway and create a clinically significant airway obstruction.

The dorsal hump often presents concomitantly with a dependent and underprojecting nasal tip. This can exaggerate the amount of dorsal resection required. Understanding this dynamic dorsum-to-tip interplay helps prevent dorsum overresection, because some degree of dorsum tip balance is achieved through proper tip positioning alone. A 6- to 10-mm tip-to-dorsum height differential can serve as a useful guideline as to the amount of dorsal resection and dome projection needed. The surgeon can position the tip-defining points where desirable using a double hook or two single hooks throughout the graduated dorsum reduction, to estimate the final dorsum-tip relation. If the tip complex is stable, less tip-to-dorsal height differential is indicated. This will prevent unnecessary dead space in the supratip region.

Cartilage Framework Nasal Tip

An ill-defined nasal tip that is bulbous or boxy, with overlying thick skin, mandates more aggressive tip modification. Standard invisible/nonpalpable suturing and grafting techniques24 can be supplemented by more visible grafting techniques. A stepwise approach that begins with placement of a columellar strut (or septal extension graft), medial crural sutures, transdomal sutures, interdomal sutures, medial crura-septal sutures, and tip grafting and ends with nostril/base shaping improves the predictability of the long-term nasal tip contour. Although the underlying domal width and angle of divergence may appear adequate, the thickness of the overlying soft tissue/skin thickness (particularly in the supratip) blunts this configuration and mandates the use of multiple tip-suturing techniques (and grafts) to improve tip contour and projection. Tip stability is crucial, as a postoperative “pollybeak” deformity is not uncommon in this ethnic group.

The lower lateral, middle, and medial crural cartilages are often weak and thin relative to the heavy skin/soft-tissue sleeve. Therefore, the tip is prone to postoperative loss of projection and definition, unless support cartilages are adequately augmented. The insufficient middle crura and medial crura increase the need for both a columellar strut to lengthen/stabilize the nasal base, and Sheen-type and/or Peck onlay grafts to create aesthetic infratip double breakpoints. The use of a strong, floating (or fixed) columellar strut or septal extension graft, as described by Byrd et al., may also be required.

The lateral crura are commonly wide, thin, and malpositioned, and cannot contribute substantially to overall alar arch strength. When lateral crural malposition cannot be corrected with cephalic trim-transposition, transection at the accessory chain along with repositioning and a lateral crural strut graft or batten graft becomes necessary. An alar contour graft is often indicated to improve alar arch shape, improve external valve function, and prevent secondary alar notching. Toriumi also places importance on the position of the cephalic lateral crural margin relative to the caudal margin. When the cephalad margin is oriented in a different plane than the caudal margin, inherent lateral crural instability exists and should be addressed before tip shaping. Thus, the lower lateral crura position must be maintained. Lastly, redundant scroll area and caudal septal vestibular resection and suturing may be required. Vestibular lining plays an important role in strength and maintenance of nasal tip position and shape.

Alar Base

Alar flaring and increased interalar width are common. Conservative alar base surgery is required for nostril flaring, elongated nasal sidewalls, a widened nasal base, large alae, and alar (nostril) asymmetries. If alar flaring (alar rim >2 mm outside the medial canthal line) is present with normal nostrils, flaring is corrected by limiting the excision to only the alar flare.

Alar and nostril position and asymmetries were also observed. When alar flaring is present with excessive nostril size (increased interalar width), a complete wedge excision that extends into the vestibule 2mmabove the alar groove is needed. Excessive alar base narrowing should be avoided at all costs, which may create racial incongruity.

In Middle Easterners, alar-columellar disharmony often presents as a “hanging columella” deformity and/or hanging ala. Primary alar retraction or excess nostril show is rare.2,9 Correction of excess “columellar show” may require medial crural septal sutures and caudal septal resection, to improve/maintain tip rotation. Many Middle Eastern patients express significant concern about tip overrotation, which is a widespread problem in improperly treated Middle Eastern noses. This is perhaps the most important imbalance to avoid.

The alar base is frequently displaced cephalad relative to a plunging tip. On animation, this imbalance between the caudally dependent nasal tip and cephalically positioned alar base is exaggerated. However, the degree to which the alar base needs to be caudally repositioned decreases after proper nasal tip rotation is achieved.

Nostrils

The nostrils are assessed three-dimensionally on lateral, frontal, and basilar views for shape and asymmetry. Tip-to-nostril disproportion often presents as tip proportion greater than 40 percent and a nostril proportion less than 60 percent. A nostril-to-tip ratio of approximately 60:40 is aesthetic, similar to other ethnic groups.40,41 After proper correction of tip rotation/projection, alarcolumellar discrepancy,39 and alar base positioning, residual nostril abnormalities become even more apparent. Flaring medial crural footplates, a short nostril deformity41 (soft triangle excess), or enlarged/improperly angled nostril apertures are usually the culprits.

Asymmetric and excessive medial crural footplate flaring is corrected through suturing techniques, with or without footplate excision. Excess soft tissue is commonly present in the intercrural space and should be excised to further enhance nostril and columellar shape.

Nostril-tip disproportion can appear exaggerated during further intraoperative inspection. When infratip lobule augmentation and tip projection are increased without addressing a short nostril, a short nostril deformity results, because of excess tip/lobule bulk. Guyuron et al. describe soft triangle excision and/or tip-suturing techniques to elevate the nostril apices and elongate the nostrils.

Depressor Septi Nasi Muscle

The depressor septi nasi muscle is often hypertrophied, resulting in a hyperdynamic nasal tip. This exaggerates the dorsal hump as the tip plunges toward the nasal spine.43 An aesthetic improvement in upper lip length (static and dynamic) can be achieved with depressor septi transection/transposition.43 It is unknown exactly to what degree the depressor muscle contributes to the “plunging” tip because simultaneous rhinoplasty maneuvers also elevate the tip. Isolate analysis of the depressor septi nasi muscle is currently being investigated using botulinum toxin type A injection preoperatively.

The authors express their deepest gratitude to Holly Smith, B.F.A., for assistance with the images used in this article. Her attentive eye to aesthetic details allowed the authors to demonstrate their concepts with clarity.

1. Rohrich RJ, Muzaffar AR. Rhinoplasty in the African-American patient. Plast Reconstr Surg. 2003;111:1322.

2. Ricketts RM. Divine proportions in facial esthetics. Clin Plast Surg. 1982;9:401.

3. Farkas LG, Kolar JL. Anthropometrics and art in aesthetics of women’s faces. Clin Plast Surg. 1987;14:599.

4. Rohrich RJ, Kenkel JM. The definition of beauty in the Northern European. In: Matory WE Jr, ed. Ethnic Considerations for Facial Aesthetic Surgery. Philadelphia: Lippincott- Raven; 1998:85–98.

5. Rohrich RJ, Janis JE, Kenkel JM. Male rhinoplasty. Plast Reconstr Surg. 2003;112:1071.

6. Bizrah MB. Rhinoplasty for Middle Eastern patients. Facial Plast Surg Clin North Am. 2002;10:381.

7. Beheri GE. Rhinoplasty in Egyptians. Aesthetic Plast Surg. 1984;8:145.

8. Foda HM. External rhinoplasty for the Arabian nose: A columellar scar analysis. Aesthetic Plast Surg. 2004;28:312.

9. Guyuron B. The Middle Eastern nose. In: Matory WE Jr, ed. Ethnic Considerations for Facial Aesthetic Surgery. Philadelphia: Lippincott-Raven; 1998:363–372.

10. Ofodile FA, Bokhari F, Ellis C. The Black American nose. Ann Plast Surg. 1993;31:209.

11. Ofodile FA, Bokhari F. The African-American nose: Part II. Ann Plast Surg. 1994;34:123.

12. Snyder GB. Rhinoplasty in the Negro. Plast Reconstr Surg. 1971;47:572.

13. Flowers RS. The surgical correction of the non-Caucasian nose. Clin Plast Surg. 1977;4:69.

14. Rees TD. Nasal plastic surgery in the Negro. Plast Reconstr Surg. 1969;43:13.

15. Ortiz-Monasterio F, Olmedo A. Rhinoplasty on the mestizo nose. Clin Plast Surg. 1977;4:89.

16. Daniel RK. Hispanic rhinoplasty in the United States with emphasis on the Mexican American nose. Plast Reconstr Surg. 2003;112:244.

17. Ofodile FA, James EA. Anatomy of alar cartilages in blacks. Plast Reconstr Surg. 1997;100:699.

18. Gunter JP, Hackney FL. Clinical assessment and facial analysis. In: Gunter JP, Rohrich RJ, Adams WP, eds. Dallas Rhinoplasty: Nasal Surgery by the Masters. Vol. 1, 2nd ed. St. Louis, Mo.: Quality Medical; 2007:105.

19. Flowers RS. Rhinoplasty in Oriental patients: Repair of the East Asian nose. In: Daniel RK, ed. Rhinoplasty: Aesthetic Plastic Surgery. Boston: Little, Brown; 1993.

20. Adams WP Jr, Rohrich RJ, Hollier LH, Minoli J, Thornton LK, Gyimesi I. Anatomic basis and clinical implications for
nasal tip support in open versus closed rhinoplasty. Plast Reconstr Surg. 1999;103:255.

21. Constantian MB. Functional effects of alar cartilage malposition. Ann Plast Surg. 1993;30:487.

22. Constantian MB. The boxy nasal tip, the ball tip, and alar cartilage malposition: Variations on a theme. A study in 200 consecutive primary and secondary rhinoplasty patients. Plast Reconstr Surg. 2005;116:268.

23. Guyuron, B. Footplates of the medial crura. Plast Reconstr Surg. 1998;101:1359.

24. Ghavami A, Janis JE, Acikel C, Rohrich RJ. Tip shaping in primary rhinoplasty: An algorithmic approach. Plast Reconstr
Surg. (in press).

25. Behmand RA, Ghavami A, Guyuron B. Nasal tip sutures: Part I. The evolution. Plast Reconstr Surg. 2003;112:1125.
26. Guyuron B, Behmand RA. Nasal tip sutures: Part II. The interplays. Plast Reconstr Surg. 2003;112:1130.

27. Tebbetts JB. Shaping and positioning the nasal tip without structural disruption: A new systematic approach. Plast Reconstr Surg. 1994;94:61.

28. Rohrich RJ, Adams WP Jr. The boxy nasal tip: Classification and management based on alar cartilage suturing techniques. Plast Reconstr Surg. 2001;107:1849.

29. Gonzales-Ulloa M. The fat nose. Aesthetic Plast Surg. 1984;8: 135.

30. Rohrich RJ, Muzaffar AR, Janis JE. Component dorsal hump reduction: The importance of maintaining dorsal aesthetic
lines in rhinoplasty. Plast Reconstr Surg. 2004;114:1298.

31. Guyuron B. Guarded burr for deepening of nasofrontal junction. Plast Reconstr Surg. 1989;84:513.

32. Barton FE. Personal communication, 2006.

33. Sheen JH, Sheen A. Aesthetic Rhinoplasty. 2nd ed. St. Louis, Mo.: Mosby; 1987.

34. Peck GC. Techniques in Aesthetic Rhinoplasty. New York: Thieme- Stratton; 1984.

35. Byrd S, Andochick S, Copit S, Walton KG. Septal extension grafts: A method of controlling tip projection, rotation, and
shape. Plast Reconstr Surg. 1997;100:999.

36. Gunter JP, Friedman RM. Lateral crural strut graft: Technique and clinical applications in rhinoplasty. Plast Reconstr
Surg. 1997;99:943.

37. Rohrich RJ, Raniere J Jr, Ha RY. The alar contour graft: Correction and prevention of alar rim deformities in rhinoplasty.
Plast Reconstr Surg. 2002;109:2495.

38. Toriumi DM. New concepts in nasal tip contouring. Arch Facial Plast Surg. 2006;8:156.

39. Gunter JP, Rohrich RJ, Friedman RM. Classification and correction of alar-columellar discrepancies in rhinoplasty.
Plast Reconstr Surg. 1996;97:643.

40. Daniel RK. Rhinoplasty: Large nostril/small tip disproportion. Plast Reconstr Surg. 2001;107:1874.

41. Guyuron B, Ghavami A, Wishnek SM. Components of the short nostril. Plast Reconstr Surg. 2005;116:1517.

42. Guyuron B. Alar rim deformities. Plast Reconstr Surg. 2001; 107:856.

43. Rohrich RJ, Huynh B, Muzaffar AR, Adams WP Jr, Robinson JB Jr. Importance of the depressor septi nasi muscle in rhinoplasty: Anatomic study and clinical application. Plast Reconstr Surg. 2000;105:376.

44. Ghavami A, Janis JE, Guyuron B. Regarding the treatment of dynamic tip ptosis using botulinum toxin A. Plast Reconstr
Surg. 2006;118:263.23. Guyuron, B. Footplates of the medial crura. Plast Reconstr Surg. 1998;101:1359.
